Technical Details
Frameset
Frame:
Lightweight aluminium with Powder Coat Finish | 1 1 / 8" head tube | 140mm post mount | 9 x 135mm QR
Fork:
Lightweight Aluminium with Powder Coat Finish | 140mm Post Mount | 9 X 100mm QR
Cockpit
Stem:
BMC | 35mm Length | 6° Angle
Handlebar:
SDG Slater | 650mm Wide | 20mm Rise | 5° Sweep | 31.8mm Clamp
Seat
Seatpost:
Alloy | 27.2mm Diameter | 300mm Length | 15mm Offset
Saddle:
SDG Fly Jr
Drivetrain
Crankset:
Lightweight Forged Alloy Cranks | 140mm Length
Chainrings:
32T
Cassette:
Sunrace
Cassette Size:
11-34T
Chain:
SRAM
Rear Derailleur:
SRAM X4 | Medium Cage
Shifters:
SRAM X4 Trigger
Gears:
1 x 8
Bottom Bracket:
BSA Threaded Bottom Bracket
Brakes
Brake Levers / Calipers:
TEKTRO HD-M286 | Short Reach Levers
Rotors:
TEKTRO TR140-22
Rotor Size (F/R):
140mm
Wheels
Rims:
DD32
Hubs (F/R):
CNC Machined Alloy | Sealed Bearings | Quick Release
Tires:
Kenda Booster | 24 x 2.4"
Additional Information
Tire Clearance:
58mm measured tire
ASTM Classification:
Level 3
System Weight Limit:
60kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | 24" |
|---|---|
| Rider Height | 120-145 |
| Reach | 350 |
| Stack | 507 |
| Bar Rise | 20 |
| Bar Sweep | 5 |
| Bar Width | 650 |
| BB Drop | 40 |
| Crank Length | 140 |
| Fork Length | 412 |
| Fork Rake | 40 |
| Front Center | 538 |
| Head Tube | 105 |
| Head Tube Angle | 68 |
| Rear Center | 392 |
| Seat Angle | 73 |
| Seat Tube | 300 |
| Seatpost Length | 300 |
| Seatpost Offset | 15 |
| Standover Height | 580 |
| Stem Angle | ±6 |
| Stem Length | 35 |
| Top Tube | 505 |
| Trail | 82 |
| Wheelbase | 972 |
